T-REX 700E 3G Combo KX018E02

T-REX 700E 3G Combo KX018E02

●T-REX 700E 3G Kits Set X1
●Aluminum Tail Boom X1
●3K Carbon Fiber Tail Boom X1
●690D Carbon fiber blades X1
●DS610 Digital servoX3 set
●DS650 Digital servo X1
●Flybarless System X1 set
●700M Brushless Motor X1
●105mm 3K Carbon Fiber Tail Blades X1 Set

Radio transmitter and electronic equipment required for assembly:
●Transmitter(7-channel or more, helicopter system) & Receiver
●ESC ,2x 6S lipos, BEC, Pitch Gauge

$ 949.99 Unavailable Back
Quantity:

Specification(T-REX 700E) :
● Length: 1328mm
● Height: 408mm
● Main Blade Length: 690mm
● Main Rotor Diameter: 1562mm
● Tail Rotor Diameter: 281mm
● Motor Drive Gear:12T
● Main Drive Gear:115T
● Autorotation Tail Drive Gear: 104T
● Tail Drive Gear: 24T
● Drive Gear Ratio: 1:9.58:4.33
● Weight(With Motor): 2830g
● Flying Weight: Approx. 4700g

Specification(T-REX 700E) :
●Features
1.All metal, highly precise main blade control system, with excellent durability and superior control precision.
2.Design concept based on large competition helicopters, for excellent static and dynamic performance.
3.New lateral adjustable metal left/right control bellcrank arms and elevator control arms, enabling the most ideal endpoint travel adjustment for 3G flybarless as well as flybar system, while increasing servo resolution for improved control precision.
4.Innovative sliding battery tray rails imbedded into the 3K side frames, allowing for quick battery access as well as battery protection. In addition, the system improves the overall rigidity of side frames, as the same time raising the center of gravity.
5.Top mounted motor base bringing the motor’s center of gravity much accurate, improving 3D agility and allowing blade drafts to cool the motor effectively.
6.Utilizing module 1 gear pitch for improved power sustainability of main gear.
7.Uniquely designed fixed motor mount with 3 bearing support blocks, providing absolute support for motor shaft, dramatically reducing gear mesh variance as result of instantaneous torque. In addition, this system strengthen the lack of support on high power outrunner motors, eliminating gear stripping issues, while increasing motor power transfer efficiency and main gear longevity.
8.Easy access top mounted ESC platform to take advantage of main blades airflow for effective cooling.
9.New lightweight H-shaped electric devices retention system for protection, as well as ergonomically correct design to simplify operation.
10.High grade painted fiberglass canopy with new 4 point anti-vibration mounting mechanism to simplify installation.
11.Wide +/- 15 degree pitch range for superior 3D performance and explosive power.
12.CNC twice-machined gear for superior balance and stability.
13.High speed rated thrust bearings incorporated into tail blade grips.
14.Utilizes high efficiency tail drive shaft system and high strength 3K carbon fiber tail boom.
15.Highly rigid 3K carbon fiber side frames for simple maintenance.
16.Tail blades, tail boom, and tail boom supports all utilize high strength carbon fiber material.
17.High torque rated one way bearing base.
18.New lightweight landing gears.

Users must have a certain concept of security to operate the R/C helicopters.
Be sure to read and comply with related safety notes of instruction manual before flying.
